The brushless DC motor driver is the core electronic equipment used to control the operation of the brushless DC motor. Since the brushless motor itself has no brushes and no mechanical commutator, it must rely on the drive to complete the electronic steering, speed regulation and protection functions.
And this "electronic steering + control logic" is the core function of the drive
Without a drive, a brushless motor is a set of coils and magnets; With the drive, it is an efficient and intelligent rotating power source.
Therefore, the memory of the drive is not optional, but must be core!
The rotor position is detected by Hall sensors or sensorless algorithms, and the current direction of the motor coil is switched in real time to generate continuous torque in the motor.
Receives an external PWM signal or analog voltage for precise speed adjustment.
Realize soft start and soft stop of the motor to prevent shock and excessive load.
It protects the motor and drive circuit, improving system safety and longevity.
The motor is controlled to run forward and backward, which is suitable for occasions that require commutation.
| Module | Feature description |
| MCU or driver chip | Control commutation logic, process speed signal |
| MOSFET Power stage | Converting control signals to high currents driving motor windings |
| Hall signal interface | Reading the rotor position (Hall version available) |
| PWM speed control interface | Receives an external speed control signal |
| Power module | Provide DC power input, generally 12V/24V/48V/72V, etc |
| Cooling system | Heatsink/fan to reduce the driver IC or MOS temperature |
The voltage range of the brushless DC motor driver (BLDC driver) depends on the rated voltage and application scenario of the supporting motor, usually covering 12V ~ 96V, of which the common ones are 24V, 36V, 48V, 72V, 96V.
The following are the typical uses and characteristics of different voltage levels:
| Driver voltage | Application scenarios | Features |
| 12V | Small fans, computer radiators, toy cars | High current and low power, commonly found in low-power electronics |
| 24V | Mixers, light electric vehicles, medical equipment, office equipment | Low cost, suitable for low power, medium speed equipment |
| 36V | Electric scooters, portable devices | It is gradually becoming popular in light-load and high-speed equipment |
| 48V | Industrial oil pumps, power tools, logistics robots | The power can reach 750W~1500W |
| 72V | Electric motorcycles, heavy-duty robots, servo systems | Suitable for high power, high speed applications |
| 96V and above | Heavy-duty AGVs, electric forklifts, industrial automation systems | High pressure and efficiency, but cost and control system complex |
Driver voltage selection recommendations:
▲The rated voltage of the motor must be matched: too high will burn the motor, too low to start or insufficient torque;
▲Consider the current capacity: the lower the voltage, the greater the current that the driver needs to carry, and the selection of wire and driver should also be considered simultaneously;
▲Trade-off between efficiency and energy consumption: the high-voltage drive system has better efficiency, small line loss, and is suitable for medium and long-distance transmission;
It is an independent control unit used to control the power-on sequence, speed, direction and protection functions of the brushless DC motor.
The usual structure is: driver + external brushless motor (split type)
It is a product that integrates "driver circuit + control unit + motor body" into a whole, and the user only needs to supply power and send instructions to operate.
Suggested use cases
✅ Scenarios using "split" drives:
Industrial projects require flexible speed/power/change drive solutions
The motor and the drive are located far apart
Frequent motor maintenance (e.g. oil pumps, fans)
✅ Scenarios with "integrated" drive motors:
Space-constrained equipment (e.g. small robots, AGV trolleys)
A system that requires quick access and low maintenance
The project has high requirements for simplified wiring and electromagnetic compatibility
