BG-F4214 380KV 400KV 8S 6KG Payload BLDC UAV Motor for 13inch FPV

Fpv motor

BG-F4214 380KV 400KV 8S 6KG Payload BLDC UAV Motor for 13inch FPV

TYPE: Fpv motor Get Free Solutions Download PDF

The BGS F4214 8S-380KV outrunner brushless motor is specially made for 13-inch freestyle FPV drones. It features strong torque, stable power output and low vibration, perfectly matching 8S batteries and 13-inch propellers for smooth freestyle flying and aerial shooting.

Motor dimensions42*14mm

Number of slots12N14P

Copper wire grade200℃

Shaft diameterIN: 6 mm

Motor weight197g

Service life>1000h

Technical specificationsView details Basic dataView details Test dataView details DrawingView details ApplicationsView details Custom solutionsView details

Technical Specifications

Recommended 4214 UAV Motor
Type:4214	Motor Dimension:42*14mm
Magnet:Zinc-Plated	Coil Insulation Test:500V Withstand
Dynamic Balance StabdardsP:≤5mg	Configuration:12N14P
Shaft Diameter:25mm	Lead:18AWG*250mm
Wire Length:500mm	Prop Adapter Shaft Thread:M5X14.5mm
Recommended Voltage:KV380	Idle Current (10V):1.35A
Rated Voltage (LiPo):8S	Peak Current:45.8A
Max Thrust:6.06kg	Weight(Incl. Cable):197g

Advantages

Basic Data

MODEL	KV Value	Maximum power	Maximum current	Pull	Efficiency	Propeller	Battery	ESC
BGS-F4214	KV	W	A	g	g/W	/	S	A
BGS-F4214	380	1366.9	45.8	4700	3.43	GEMFAN1308	8	/

Test Data

Model	Throttle	Voltage	Current	Input Power	Speed	Thrust	Power Efficiency
BGS-F4214 -380KV GEMFAN1308 8S	%	V	A	W	RPM	gf	gf/W
	35	50	3.68	184	7238	1084	5.9
	40	50	5.84	292	8385	1505	5.2
	45	50	7.77	388.5	9144	1826	4.7
	50	50	10.22	511	10256	2397	4.7
	55	50	12.34	617	10825	2629	4.3
	60	50	16.09	804.5	11658	3071	3.8
	65	50	19.73	986.5	12430	3501	3.5
	70	50	22.7	1135	12955	3813	3.4
	75	50	24.95	1247.5	13418	4173	3.3
	80	50	33.72	1686	14810	4810	2.9
	85	50	38.91	1945.5	15259	5190	2.7
	90	50	44.8	2240	15645	5491	2.5
	95	50	49	2450	15946	5771	2.4
	100	50	53.82	2691	16092	6068	2.3

Drawing

Customizable Solutions

Parts

Applications


Designed Around Torque Rather Than Speed

The motor features a large 42 mm stator diameter combined with a 14 mm stator height, providing a substantial increase in electromagnetic volume compared with smaller motors such as 3110 or 3515 models.This larger magnetic circuit allows the motor to generate significantly more torque at lower rotational speeds, making it ideal for turning large propellers efficiently while maintaining lower current consumption.

Unlike high-KV racing motors that prioritize acceleration and top speed, the 4214 focuses on efficiency, lifting capability, and endurance.

Typical applications include:

-Industrial inspection drones

-Mapping and surveying UAVs

-Medium cargo delivery drones

-Agricultural spraying drones

-Heavy-lift cinematic drones

-Long-endurance reconnaissance platforms

-Emergency supply transport UAVs

Outstanding Thrust Performance

Depending on KV configuration, operating voltage, and propeller selection, the 4214 motor can deliver peak power outputs ranging from approximately 2.5 kW to more than 4.5 kW.

When paired with optimized carbon fiber propellers, individual motor thrust can exceed 8 kg to 12 kg, allowing octocopter platforms to achieve payload capacities suitable for industrial logistics and professional applications.

The large torque reserve offers several operational advantages:

1.Faster climb rates;

2.Stronger wind resistance;

3.Improved flight stability under heavy payload conditions;

4.Lower motor loading during cruise flight;

5.Increased safety margins during takeoff and landing.
